The Fix-It Discussion Panel: Replacing a window regulator

Author: Adam Gibbs  Date Posted:31 July 2014

Is your window stuck?



It may be your window regulator!

Window Stuck?

Window regulators and motors, located within car doors, help raise and lower windows of the vehicle. Since we use our windows frequently, window regulators and window motors are some of the most actively used parts in any vehicle. For this reason, window regulators and window motors are subject to high wear and tear that lead to breakage and inconvenience. Some of the common reasons for window regulator and window motor failure(s) include excessive strain and breakage caused by forcing the window, damaged window track, old or worn pulley and cable lines, and general wear and tear. Therefore, the quality of the design and material is important to the reliability of the window regulator and motor.

Panel House stock a large range of new, second hand and reconditioned window regulators for most makes and models both manual and electric.

Contact one of our friendly staff for pricing and availability.


How to install your new window regulator
Note: This is a general guide for all vehicles

Step 1 - Remove the door and interior window handles.
Step 2 - Remove all screws holding the door panel to the door shell. Using a door panel trim tool, carefully pry the door panel away from the door at the bottom. Refer to the vehicle specific service manual for screw and clip locations.
Step 3 - If necessary, disconnect the electrical connector from the power window switch. Remove the door panel.
Step 4 - Remove the vapor barrier / water shield. Take care not to rip or tear - if re-using plastic barrier.
Step 5 -  Disconnect the glass from window regulator.
Step 6 - Tape the glass to door frame. The glass should not require removal.
Step 7 - Remove the window regulator mounting bolts. Slide the regulator assembly out through the interior access opening of the door. If applicable, remove the window motor.
Step 8 - Attach the original motor to the new window regulator and install the regulator assembly. Be sure to apply lubricant; white lithium grease - to the window tracks and moving parts. Tighten the mounting bolts.
Step 9 - Install the window back onto the window regulator. Re-install the vapor barrier.
Step 10 - Reconnect the electrical connector to the power window switch and reconnect the battery cable connection - or temporarily install the window handle. Test the window operation before proceeding.
Step 11 - Re-install the door trim panel and handles.
Step 12 - Test the window for proper operation by rolling the window completely up and down.
